| Item | specifications | |
| Performance parameters | Bucket capacity（m³） | 1.1 |
| Bucket width（mm） | 2000 | |
| Rated load（kg） | 2000 | |
| Max Climb Capability（°） | 30 | |
| Minimum turning radius of bucket during loading（mm） | 4996 | |
| Main dimensions and weight parameters | Overall length (with accessories) （mm） | 6050 |
| Maximum width（mm） | 1980 | |
| Maximum height（mm） | 2930 | |
| Maximum dumpling height (- 45 ° dumpling angle)（mm） | 3500 | |
| Corresponding dumpling distance (- 45 °dumpling angle)（mm） | 800 | |
Minimum ground clearance （mm） | 360 | |
Track width (left / right) （mm） | 1580 | |
| Wheelbase (front / rear)（mm） | 2600 | |
| Overall weight（kg） | 5100 | |
| Engine | Model | Huafeng 4102 Turbocharged |
| Type | Direct Injection | |
| Rated power（kw） | 76 | |
| Number of cylinders | 4 | |
| Bore / stroke(mm) | 102 | |
| Torque converter | Type | Single stage three element torque converter |
| Braking system | Oil cooling mode | Air cooling |
| Service braking mode | Gas cap oil,pliers disc brake | |
| Parking brake mode | manual operation,pliers disc brake | |
| Drive axle | Type | Tyre Type |
| Tire size | 1670-20 | |
| Front tire pressure（MPa） | 3 | |
| Rear tire pressure（MPa） | 3 | |
| Axle(Main drive and wheel reducer) | In the wheel side | |
| Steering system | Steering cylinder - cylinder diameter * piston rod diameter * stroke（mm） | 70*45 |
| Articulated steering angle （°） | 35 | |
| Boom cylinder - cylinder diameter * piston rod diameter * stroke（mm）Boom | 90*50 | |
| Bucket cylinder - cylinder diameter * piston rod diameter * stroke（mm） | 120*80 | |
| Working device | Multiway valve model | 15-2-2 |
| Refueling capacity | Fuel tank（L） | 80 |
| Hydraulic tank（L） | 80 | |
